Equipment applicationCurrent Position：Home Page > Packaging equipment
 |
To view the relevant pneumatic field foam packaging machine content, please click here
For information about electric field foam packaging machine, please click here
The production of polyurethane buffering foam packaging foam can be selected from pneumatic field foam packaging machine or electric field foam packaging machine. The pictures of the machine are as follows:
Pneumatic field foam packaging machine is used for packaging all kinds of precision instruments, pneumatic actuators, locks, electronic scales, fans, motors, valves, lamps, auto parts and crafts, etc.
Technical parameters:
raw material ratio | 1:1（fixed） |
Raw material viscosity range | 200～1000CPS (at room temperature） |
Raw material output | 3～5Kg/min or 50～80g/s |
Temperature setting range | 0～90℃ |
power requirement | single phase 220V 50HZ |
Pneumatic working pressure | 0.6-0.8MPa |
air demand | 1m3/min |
Heat insulation pipe length | 6m |
Short pipe length of gun | 4m |
boundary dimension | 1100X480X380 |
hauled weight | 100Kg |
| This table is standard model configuration. If it does not conform to the reality, please refer to the additional "machine configuration list" sent randomly. | |
Electric field foam packaging machine heats raw material A and B in the tube and mixes them proportionally in the nozzle. When the two materials are mixed, the reaction will occur and the polyurethane foam will be generated to protect your product. It consists of four main parts: integrated circuit controller (main engine), two electric feed pumps, an all-electric feed gun and two internal heating thickened feed delivery pipes.
Application: this equipment is used for packing all kinds of precision instruments, pneumatic actuators, locks, electronic scales, fans, motors, valves, lamps, auto parts and handicrafts, etc. It can also be used for small filling thermal insulation foam.
Technical parameters:
project | arguments |
A Edge temperature setting range | 0℃-80℃ |
B Edge temperature setting range | 0℃-80℃ |
Flow setting range | 0.00Kg/min-4Kg/min |
Standby flow is | 2.00 Kg/min It's factory set |
A Side standby pressure range | 0-6KG |
B Side standby pressure range | 0-6KG |
